77 Chapter 5
Exploded Parts List
Note: Please refer to RSPL for updated Part Number.
Item Part Number Description
1 23.89602G001 POLYGON MIRROR (t1.1mm)
2 23.89620G001 CONDENSER 1 X26mm BK7 SPHERE
3 23.89620G002 CONDENSER 2 X26mm BK7 SPHERE
4 51.89614G001 ENGINE BASE BMC EP759/PD726
5 51.89637G001 ENGINE MIRROR ANTI LIGHT MYLAR EP759/PD726
6 52.85808G001 PORON-LENS BLACK XB31
7 52.89625G001 LAMP HOUSING STEAMTIGHT TOP F12 3.2t EP759/PD726
8 52.89626G001 LAMP HOUSING STEAMTIGHT SIDE F12 1.6t EP759/PD726
9 61.89602G001 LAMP HOUSING Mg ALLOY AZ91D EP759
10 61.89611G001 MIRROR SPRING PLATE SUS301 0.25t EP759/PD726
11 61.85A05G001 ROD MASK BRACKET PH730
12 61.89621G001 ROD SPRING SUS301 0.25t EP759/PD726
13 70.83N03G001 ASSY COLOR WHEEL MODULE PD726
14 70.85A04G001 ASSY ROD MODULE PH730
15 70.83N21G001 ASSY RELAY LENS MODULE PD726
16 85.1A122G060 SCREW PAN MECH M2*6 Ni
17 85.1A126G040 SCREW PAN MECH M2.6*4 Ni
18 85.1A126G080 SCREW PAN MECH M2.6*8 Ni
To Next Page
