Exploded Parts List
Note: Please refer to RSPL for updated Part Number.
Item Part Number Description
1 85.1A123G060 SCREW PAN MECH M3*6 NI
2 85.WA123G060 SCREW PAN TAP M3*6 Ni
3 80.83405G001 PCBA THERMAL SENSOR BD EzPro 730/735 ID=90
4 70.85A16G001 ASSY BOTTOM COVER MODULE PH730
5 70.83N12G001 ASSY LVPS MODULE PD726
6 70.85A10G001 ASSY LAMP DRIVER MODULE PH730
7 70.83N14G001 ASSY AXIAL FAN 92*25 MODULE PD726
8 86.03123G035 HEX CAP HEAD NUT M3*0.5P L3.5
9 75.83N05G001 ASSY PRE ELEVATOR MODULE PD726
10 85.TA326G070 SCREW CAP TAP M2.6*7 WASHER BLACK
11 85.WD123G080 SCREW PAN TAP 3*8 W/WASHER Ni
12 80.83N05G001 PCBA IR SENSOR BOARD FOR PD72
13 52.89601G001 ADJUST FOOT RUBBER EP910
14 52.83N14G001 ADJUST FOOT RUBBER LEFT PD726
15 75.83N06G001 ASSY WIND TUNNEL MODULE PD726
16 70.83N16G001 ASSY INTERRUPT SWITCH MODULE PD726
17 51.00075G001 WIRE MOUNTS PG-FW-4D PD120
18 70.83N17G001 ASSY BLOWER FAN 50*20 MODULE PD726
19 52.89631G002 LAMP TO BTM INSULATOR RUBBER EP759/PD726
20 51.83N32G001 MYLAR FOR FRONT IR LENS PD726
21 52.83N11G001 WIND TUNNEL DISCONNECT SPONGE PD726
22 41.85A01G001 EMI GASKET / 10*27*20
To Next Page
