Introduction
Connection Ports
1. USBConnector
2. HDMIConnector
3. DVIInputConnector
4. VGAInputConnector(PCAnalogSignal)
5. ComponentVideoInputConnector
6. S-VideoInputConnector
7. RS232Connector
8. Kensington
TM
Lock Port
9. PowerSocket
10. VGAOutputConnector(MonitorLoop-throughOutputConnec-
tor)
11. AudioInputConnector
12. CompositeVideoInputConnectort
Below items are for PD726W only:
13. Lan(RJ45Portfor10/100MEthernet)
14. AudioOutputConnector
15. ResetButton
16. StatusIndicator
17. Antenna
For PD726W
only
1
2
3
4
11
8
12
9
10
65
7
16 15 14 13
17
