Right view
Rear view
# Icon Item Description
1 Release lever Releases the notebook from the
ProDock.
# Icon Item Description
1 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
Note: Wrap the security lock cable
around an immovable object such as a
table or handle of a locked drawer. Insert
the lock into the notch and turn the key
to secure the lock. Some keyless models
are also available.
2
Ethernet (RJ-45) port
1
Connects to an Ethernet 10/100/1000-
based network.
3 External display
(VGA) port
4
Connects to a display device (e.g.,
external monitor, LCD projector).
