7
English
Installation
To install the monitor on your host system, please follow the steps below:
Steps
1 Connect the video cable
a Make sure both the monitor and computer are switched off.
b Connect the VGA video cable to the computer.
c Connect the digital cable
(1) Make sure both the monitor and computer are switched off.
(2) DVI Cable (Optional, only Dual-Input Model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the DVI cable to the computer.
(3) HDMI Cable (Optional, only HDMI-Input Model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the HDMI cable to the computer.
2 Connect the audio cable
a Connect an audio cable to the audio port of the monitor.
3 Connect the adapter
a Connect the AC cord to the adapter.
b Connect one end of the adapter to the monitor and the other end to a properly
grounded, AC outlet.
4 Turn on the monitor and computer
Turn on the monitor first, then the computer. This sequence is very important.
5 If the monitor does not function properly, please refer to the troubleshooting section
to diagnose the problem.
HDMI
AUDIO
VGA
DC
DC INAUDIO INHDMI 1 HDMI 2 VGA IN
VGA
VGA
HDMI
HDMI
DC INVGA IN AUDIO INHDMI 1 HDMI 2
