Acer T232HL - Exploded View Diagram with List of Items

4
1. Exploded view diagram with list of items
Item Description TPV Part No. ACER Part No.
2 PANEL 750GDB230F3P13N0AC 6M.T27M2.002
5 KEY BOARD KEPCEQB2 55.T27M2.002
7 CONVERTER BOARD LNPCEB232GNBP 55.T27M2.004
8 MAIN BOARD 756GQECB0BA070000Q 55.T27M2.001
9 USB BOARD USBEQB3Q 55.T27M2.003
LVDS-CABLE-30P-30P(A2004)-260(MB TO
PANEL)
395G801830DL41 50.T27M2.006
