Disassembly Procedures 1-9
5. Remove one (1) screw securing the WLAN module in place (Figure 1-10).
Figure 1-10. WLAN Module Removal
6. Remove the WLAN module from the mainboard connector (B) (Figure 1-11).
Figure 1-11. WLAN Module Removal
AUX
MAIN
B
WEEE Annex VII Component:
WLAN Module
