Acer TMP214-52 - LCD Module Removal (LTE SKU Only)

1-26 Disassembly Procedures
LCD Module Removal (LTE SKU Only) 0
Prerequisite:
Battery Pack Removal
1. Disconnect the tuner antenna cable from the LTE board connector (A) (Figure 1-34).
2. Unroute the tuner antenna cable from the guide on the top assembly (Figure 1-34).
Figure 1-34. LCD Module Removal
3. Detach the adhesive tape from the antennas cables (Figure 1-35).
Figure 1-35. LCD Module Removal
A
