1-28 Disassembly Procedures
9. Remove four (4) screws securing the LCD module in place (Figure 1-38).
Figure 1-38. LCD Module Removal
10. Place the device on a flat surface, top assembly facing up (Figure 1-39).
11. Lift the top assembly until it is fully open (Figure 1-39).
Figure 1-39. LCD Module Removal
