1-42 Disassembly Procedures
RTC Battery Removal 0
Prerequisite:
SSD Module Removal
1. Detach the RTC battery cable from the mainboard connector (A) and unroute the
cable from the guides on the top assembly (Figure 1-58).
2. Pry to detach the adhesive tape underneath the RTC battery (Figure 1-58).
3. Remove the RTC battery from the top assembly (Figure 1-58).
Figure 1-58. RTC Battery Removal
Follow local regulations for battery disposal.
A
WEEE Annex VII Component: RTC Battery
