Disassembly Procedures 1-43
LCD Bezel Removal 0
Prerequisite:
LCD Module Removal (HDD SKU Only) or
LCD Module Removal (LTE SKU Only)
1. Pry the LCD bezel from the bottom side to release latches (Figure 1-59).
Figure 1-59. LCD Bezel Removal
2. Continue along the left side of the bezel (Figure 1-60).
Figure 1-60. LCD Bezel Removal
