Acer X193HQ - Signal Characteristic

- 29 -
Figure-1: Preset Timing modes list
Mode
Resolution
(active dot)
Resolution
(total dot)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Nominal Pixel
Clock (MHz)
640x480@60Hz 800 x 525 31.469 59.941 25.175
640x480@72Hz 832 x 520 37.861 72.809 31.500
640x480@75Hz 840 x 500 37.500 75.000 31.500
MAC
640x480@66.66Hz
864x525 35 66.66 30.24
VESA 720x400@70Hz 900x449 31.469 70.087 28.322
800x600@56Hz 1024 x 625 35.156 56.250 36.000
800x600@60Hz 1056 x 628 37.879 60.317 40.000
SVGA
800x600@75Hz 1056x625 46.875 75.000 49.500
MAC 832x624@74.55Hz 1152x667 49.722 74.55 57.28
1024x768@60Hz 1344x806 48.363 60.004 65.000
1024x768@70Hz 1328x806 56.476 70.069 75.000
XGA
1024x768@75Hz 1312x800 60.023 75.029 78.750
MAC 1152x870@75Hz 1568x909 68.700 75.000 84.520
1152x864@75Hz 1600x900 67.5 75 108
VESA
1280x960@60Hz 1800x1000 60 60 108
1280x1024@60Hz 1688x1066 63.981 60.020 108.000
SXGA
1280x1024@75Hz 1688x1066 79.976 75.025 135.000
1280x720@60Hz 1650x750 44.955 59.940 74.176
1280x768@60Hz 1664x798 47.776 59.870 79.500
VESA
1280x768@75Hz 1696x805 60.289 74.893 102.250
WXGA
1280x800@60Hz 1680x831 49.702 59.81 83.5
1366x768@60Hz 1792x798 47.712 59.79 85.5
