Acer X193HQ User Manual

Acer
Acer –LCD-X193HQ
7
Through D-SUB/DVI connectors, this unit can support F
H
= 31~80 KHz, Fv=55~76Hz, Modes details as
below:
Mode
Resolution
(active dot)
Resolution
(total dot)
Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
Nominal Pixel
Clock (MHz)
640x480@60Hz 800 x 525 31.469 59.941 25.175
640x480@72Hz 832 x 520 37.861 72.809 31.500
640x480@75Hz 840 x 500 37.500 75.000 31.500
MAC 640x480@66.66Hz 864x525 35 66.66 30.24
VESA 720x400@70Hz 900x449 31.469 70.087 28.322
800x600@56Hz 1024 x 625 35.156 56.250 36.000
800x600@60Hz 1056 x 628 37.879 60.317 40.000
800x600@72Hz 1040 x 666 48.077 72.188 50.000
SVGA
800x600@75Hz 1056x625 46.875 75.000 49.500
MAC 832x624@74.55Hz 1152x667 49.722 74.55 57.28
1024x768@60Hz 1344x806 48.363 60.004 65.000
1024x768@70Hz 1328x806 56.476 70.069 75.000
XGA
1024x768@75Hz 1312x800 60.023 75.029 78.750
MAC 1152x870@75Hz 1568x909 68.700 75.000 84.520
1152x864@75Hz 1600x900 67.5 75 108
VESA
1280x960@60Hz 1800x1000 60 60 108
1280x1024@60Hz 1688x1066 63.981 60.020 108.000
SXGA
1280x1024@75Hz 1688x1066 79.976 75.025 135.000
VESA
1280x720@60Hz 1650x750 44.955 59.940 74.176
1280x800@60Hz 1680x831 49.702 59.810 83.500
WXGA
1366x768@60Hz 1792x798 47.712 59.790 85.500
Note: 1. Non-interlace signals only (An interlace signal cannot be display)
2. Please refer to F/W specification for more detail
3. Each frequency of Power Macintosh and Sun Ultra is a reference value
4.2.1 Digital signals
TMDS Signal: (min)
±
200mVpp@24Bit
4.3 Timing requirements
Scan Frequency Condition Specification
Horizontal
Sync polarity: (+) or (-)
31 ~ 80 KHz.
Vertical
Sync polarity: (+) or (-)
55-76Hz
Out of range
Excluding
Horizontal 31~80 KHz or
Vertical 55-76 Hz
Message “Input Not Supported” on screen
4.4 DDC data
4.4.1 EDID Standard Compliance
EDID File Format : VESA’s EDID Standard Version1.0, Revision 12,
EDID Structure : Version #1, Revision #3.
EDID Data Table : See the attached table (for example)
X193HQ VGA EDID table
0 1 2 3 4 5 6 7 8 9 A B C D E F
0
00 FF
FF FF FF FF FF 00 04 72 67 00 00 00 00 00
1
00 00 01 03 08 29 17 78 EA 3D 85 A6 56 4A 9A 24
2
12 50 54 BF EF 90 81 C0 81 00 81 80 81 40 71 4F
3
01 01 01 01 01 01 66 21 56 AA 51 00 1E 30 46 8F

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
