Acer X193HQ User Manual

1
1
Table of Contents
Important Safety Notice .....................................................................................01
01 Product Specification ......................................................................................03
02 Flat Panel Specification ..................................................................................18
03 Exploded Diagram ...........................................................................................37
04 Troubleshooting ................................................................................................39
05 Spare Parts List ...............................................................................................44
06 Schematics and Layouts ..................................................................................45
07 Assembly and Disassembly ...........................................................................48
Appendix : User’s manual
Copyright
Copyright 2006 InnoLux Tech. Corp. Ltd
All Rights Reserved
This manual may not, in whole or in part, be copied, Photocopied, reproduced, translated, or
converted to any electronic or machine readable form without prior written permission of InnoLux
Tech. Corp. Ltd.
Acer X193HQ Service Manual

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
