Acer –LCD-X193HQ
46
03 Exploded Diagram
3.1 Screw List
Item Part No. Description Qty
Fixed
T(kg*cm)
Remark
1 509146305300R
SCREW,P,CROSS
W/WAS,M3*5,Zn ROHS
3 4.5~5.0
Power Board to
Chassis*3
2 509000000700R BOLT,#4-40x11.8,Ni ROHS 2 4.0±0.5 D-SUB CON*2
3 509112612500R
SCREW P T4*12 Zn-
BLK
ROHS
3 8±0.5 Hinge to Stand
4 509216608110R
SCREW,F,CROSS,M4*8,Zn,
ROHS
4 6.5±0.5 Hinge to backcover
5 509212606110R
SCREW,F,CROSS,T4*6,Zn,
ROHS(5.8~6.2)
10 6.5±0.5 Base Plate to Base
6
509112308100R
SCREW,P,CROSS,T.T-3*8,Z
n,ROHS
1 3.0~4.0
Back cover to Front
bezel
