Acer X193HQ User Manual

Acer
Acer –LCD-X193HQ
3
01 Product Specification
1. General:
Acer X193HQ is designed with LVDS interface and dual (analog and digital signal) input, it featured with embedded
universal AC power supplies and audio input. It’s a green product and meets all ROHS standard. The power button
and display control buttons are on the front of the monitor. The monitors shall automatically to display lower
resolution video modes into 1366x768 full screen display. The image can be adjusted through OSD control.
1.1 Main Features
Features Specifications
Panel source
M185XW01-V0
Maximum resolution
1366x768 @ 60Hz
Back light system 2 CCFL
Actual Resolution display WXGA(1366x768)
Pixel pitch
0.3(H) x 0.3(V)
Display area 409.8 ( H ) x230.4 ( V ) , 18.5” diagonal
Contrast ratio 10000:1(ACM ON)
Response time (Tr+Tf) 5ms (typ.)
Viewing angle
85°
°°
°(L)/ 85°
°°
°(R), 80°
°°
°(U)/80°
°°
°(D) typ. CR>=10)
Input interface
Analog(D
-
sub 15 pin)
Digita(DVI-D connector )----option
Audio system
≧
≧≧
≧ 1 W + 1 W
Power management Compatible with VESA,EPA,NUTEK,DPMS
Plug & Play VESA
University AC power supply YES
For Non-EMEA
English, Deutsch, Español, 简体中文
简体中文简体中文
简体中文, 繁體中文
繁體中文繁體中文
繁體中文, Français, Italiano, 日本語
日本語日本語
日本語
OSD language
For EMEA
English, Deutsch, Español, Dutch, Russian, Français, Italiano, Finnish
1.2 Accessories
Items VGA cable
DVI
cable
Audio cable
User’s
manual
Warranty card Quick-start Guide
Description
1.8m 1.8m 1.8m Multi Multi Multi
● ● ● ● ● ●
2. Operation Specifications
The unit should suffer no visible cosmetic damage and should operate with no degradation in display quality during
exposure to the operating conditions and after exposure to the non-operating conditions, in any sequence.
2.1 Environmental conditions
Operating Specification
Temperature range
5°C to 40°C
Relative humidity 20% to 80%
Altitude 0 to 3657M (12000 ft)
Storage

Acer X193HQ Specifications

General

Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Viewable size, vertical	230 mm
Contrast ratio (typical)	-
Viewable size, horizontal	410 mm
Viewing angle, horizontal	160 °
Digital vertical frequency	55 - 75 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	300 cd/m²
HDCP	Yes
Product color	Black
Panel mounting interface	100 x 100 mm
Power consumption (typical)	17 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	163.7 mm
Width (without stand)	454 mm
Height (without stand)	334.7 mm
Weight (without stand)	3600 g
