18 SGM1400 Series Smart Meter User Manual – SMETS2
Display
Warning
The warning icon indicates a warning condition has been detected by the meter.
Display Modes
The SGM1400-B Series meter supports eight different display modes for the UK:
•Primary
• Alternate 1
• Alternate 2
• Alternate 3 (prepayment menu)
• Engineering Menu
• HAN Signal Strength
• Active TOU
• Privacy PIN
The display also shows the status during HAN pairing and relay reconnection.
Each display mode is configurable via the corresponding display configuration
object list. Configuration involves programming the OBIS code, interface class,
and formatting information into the list. Items appear on the screen in the same
order as the list. The total number of display items in each user-configurable
display mode is 50.
The display supports both automatic and manual scrolling through display items.
The automatic scroll duration, manual scroll timeout, backlight duration, and
contrast adjustment are configurable via the display settings. Please refer to Push
Buttons on page 20 for more information on scrolling through display items.
Display Configuration
The following aspects of the display may be configured by the utility.
Auto-Scroll Duration
This setting defines the amount of time each display item will remain on the
screen during an auto-scroll operation.
Default 20 seconds
Minimum 5 seconds
Maximum 60 seconds
Disable 0 seconds
