42 SGM1400 Series Smart Meter User Manual – SMETS2
Billing Data
• TBC1 - 2 and PB Debt Payments:
• Last Collection Time
• Last Collection Amount
• Total Amount Remaining
• Emergency Credit Status
• Disconnect Switch Status
• Primary Element
Each daily data set includes a time and date stamp for when the snapshot occurred.
In the event of a power outage over the midnight boundary, the meter will perform
the daily billing snapshot once power returns after the midnight boundary. The
Daily Billing Snapshot feature can be enabled or disabled through configuration.
Monthly Billing Data
The SGM1400-B Series meter stores 13 end-of-billing data sets before
overwriting occurs.
The billing period is specified monthly. The end-of-month billing date can be
specified as the last day of the month or a date specified for each month. In the
case of a specified date, each month can be configured with a different date.
At the end of each billing period, the meter will store copies of the current
cumulative/consumption registers into non-volatile memory.
The data includes the following:
• Tariff TOU Register Matrix
• Secondary Tariff TOU Register Matrix (SGM1422-B only)
• Tariff Block Counter Matrix
• Total Active Import Register
• Secondary Total Active Import Register
If the meter is in prepayment mode, the data below will be captured at the end of
each billing period:
• Meter Balance
• Emergency Credit Balance
• Accumulated Debt Register
• TBC1 - 2 and PB Debt Payments:
• Last Collection Time
• Last Collection Amount
• Total Amount Remaining
