The Installation of Customer Display
1. Take out the fix set，open the LCD cover and loose the four screws of display pole.
Display Pole
Screw
Fix Set
Front Cover
Back Cover
2. Take out the FFC.
FFC
3. Insert the FFC cable through the display
pole as the arrow shows.
4. Fix the display pole on the scale platter.
