DVS-2500
9-
DMX Channels
Mode
Channel
Mode 1
54-CH
Mode 2
29-CH
1 Pan Pan
2 Pan Fine Pan Fine
3 Tilt Tilt
4 Tilt Fine Tilt Fine
5 Pan/Tilt Speed Pan/Tilt Speed
6 Pan/Tilt Macro Shutter
7 Shutter Picture/Video
8 Picture/Video Video Number
9 Video Number Video Speed
10 Video Speed Layer1 Picture Directory /Color
11 Red Layer1 Picture Number/Preset Color
12 Green Layer2 Picture Directory
13 Blue Layer2 Picture Number
14 Layer1 Picture Directory /Color Layer3 Picture Directory/Filter Picture
15
Layer1 Picture Number/Preset
Color
Layer3 Picture Number
16 Layer1 Center Offset Picture Macro
17 Layer1 Center Rotation Picture Macro Center Offset
18 Layer1 X Zoom Picture Macro Center Rotation
19 Layer1 Y Zoom Picture Macro X Zoom
20 Layer1 Zoom Macro Picture Macro Y Zoom
21 Layer1 Rotation Picture Macro Zoom Macro
22 Layer2 Picture Directory Picture Macro Rotation
23 Layer2 Picture Number Focus
24 Layer2 Center Offset Color mode
25 Layer2 Center Rotation Screen Format
26 Layer2 X Zoom Mirror
27 Layer2 Y Zoom Keystone
28 Layer2 Zoom Macro Source
29 Layer2 Rotation Special Function
30
Layer3 Picture Directory/Filter
31 Layer3 Picture Number
