ACME PIXEL LINE IP - Page 8

- 7 -
2 x fixed clamps for 50mm truss (version with fixed clamps)
Dimensions
1000x192x237mm
(version with fixed clamps)
39.4"x7.6"x9.3"in
1000x90x124mm
(version without fixed clamps)
39.4"x3.5"x4.9"in
Weight
8.5kgs
(version with fixed clamps)
18.7lbs
7.5kgs
(version without fixed clamps)
16.5lbs
Version with fixed clamps:
Version without fixed clamps:
Photometric Diagram:
