GB Smart Door/Window Sensor USER MANUAL
Technical Specifications
Sensor type: Magnetic
Connection: Wi-Fi, IEEE 802.11 b/g/n
Frequency range: 2.412–2.484 GHz
Maximal output radio frequency power: 17 dBm / 50.12 mW
Sensitivity: ≤10 mm
Power supply: DC 3 V (2 x AAA)
Mounting method: Screws/Double-sided tape
Compatibility: Android 4.1 and above, iOS 8.0 and above
Application: Simple Home for iOS and Android
Operating temperature: from -10°C to 40°C
Dimensions:
Sensor: 74 (H) x 22 (W) x 19 (D) mm
Magnet: 74 (H) x 11 (W) x 19 (D) mm
Material: Plastic
Colour: White
Weight:
Sensor: 26 g
Magnet: 17 g
Door/Window Sensor overview
Sensor body Magnet
Latch
button
Button
Tamper
button
LED
Latch button – designed for opening the sensor body.
LED – indicates dierent modes of the device.
Button – the main button for pairing/resetting/changing the pairing modes.
Tamper button – a security button which sends tamper notications to your
smartphone.
Installation
The sensor body and the magnet part have to be installed less than 10 mm apart
from each other when the door/window is closed.
The sensor should not be mounted directly on or near metal framing or
other large metallic objects because they may weaken the strength of the
radio signal.
The sensor should only be placed indoors and away from water and other
extreme weather conditions.
