Acoustics M 40 - Speaker Key and Controls; Speaker Rear Connections

5
EN
Key
1. Analogue phono
Connect analogue audio source
2. Analogue 3.5mm jack
Connect analogue audio source (disables phono
sockets)
3. Optical Toslink
Connect digital optical audio source
4. Speaker out
Connect passive speaker
5. Sub
Connect optional external subwoofer
6. USB
Connect computer audio source
7. Speaker position
Select left or right position in the room from the
listening position
8. EQ switch
Adjusts the bass response of the speaker
9. Bluetooth
Press to enter BT pairing mode
10. AC Power
Connect to mains power 100v – 240v
Speaker rear connections and controls
q
w
e
t
y
u
i
o
a
r
R
L
AUX
OPT
USB
RIGHT
LEFT
SUB
100V - 240V ~
50/60Hz 200 WATTS
SPEAKER OUT
Model: M 40
HD Wireless
Music System
WARNING: SHOCK HAZARD - DO NOT OPEN.
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR.
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION
210-186791
