ACP P1333401M - Page 8

Component Testing Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to oven and discharge capacitor
before servicing, unless testing requires power.
16500030 January 2012
©2012 ACP, Inc.
8
Two Magnetron Models
# 1
# 1
# 1
# 1
# 3
# 3
# 3
# 3
H.V. System # 1 H.V. System # 3
Top Rear Magnetron
Left Transformer
Top Capacitor
Diode
Left Triac
Bottom Magnetron
Right Transformer
Bottom Capacitor
Diode
Right Triac
