1. SPECIFICATION
MODEL 46SF
Drilling capacity 42 mm (1
1
/
4
")
Face mill capacity 100 mm (4”)
End mill capacity 25 mm
Head swivel 360°
Spindle taper MT-4
Spindle stroke 130 mm (5”) (PF=107mm)
Quill diameter ø 75 mm (3”)
Motor
3ø 1
1
/
2
HP
50HZ 50,110,190,380,670,1250 (4P)
Spindle speed (RPM) 6S
60HZ 60,130,230,450,800,1500 (4P)
Column diameter 115 mm (4
1
/
2
")
Swing 520 mm (20
7
/
16
")
Spindle to base (MAX.) 1365 mm (47”)
Table working area
555 x 495 mm
Overall height 2260 mm (75
9
/
16
")
Overall width 500 mm (24
5
/
32
")
Overall depth 700 mm (28")
Net / Gross weight 300 / 330 kgs
* Extra accessories
3-1/2” vise
Work light
Coolant pump Tapping switch
NT 30 spindle Collet chuck (4,6,8,10,12 mm / set)
52 pcs clamping kits
NOISE 80dB MAX
