16
0089H
Forward active energy of B phase
4
R
008BH
Forward active energy of C phase
4
R
008DH
Voltage transfer(PT)
2
R/W
008EH
Current transfer(CT)
2
R/W
008FH
State of DIDO, over-voltage, loss-
voltage
2
R
0090H
Reserve
2
R
0091H
high byte
Running state 1
1
R/W
0091H
low byte
Running state 2
1
R/W
0092H
Zero sequence current
2
R
0093H
Voltage imbalance
2
R
unit 0.1%
0094H
Current imbalance
2
R
0095H
First communication path：
Testing byte（High 8 bytes）
Stop byte（Low 8 bytes）
2
R/W
testing byte：
0： none
2： even
stop byte：
0: 1 stop byte
1: 2 stop bytes
0096H
Second communication path：
Address（High 8 bytes）
Baud rate（Low 8 bytes）
2
R/W
Same as the first
communication
path
0097H
Second communication path：
Testing byte（High 8 bytes）
Stop byte（Low 8 bytes）
2
R/W
Same as the first
communication
path
0098H-
00B1H
Reserved
00B2H
Rate no. of period 9
Start of period 9: minute
2
R/W
The first time list:
Rate No.:
1: sharp
2: peak
3: flat
4: Valley
0: no rate
00B3H
Start of period 9: hour
Rate no. of period 10
2
R/W
00B4H
Start of period 10: minute
Start of period 10: hour
2
R/W
00B5H
Rate no. of period 11
2
R/W
