17
Start of period 11: minute
00B6H
Start of period 11: hour
Rate no. of period 12
2
R/W
00B7H
Start of period 12: minute
Start of period 12: hour
2
R/W
00B8H
Rate no. of period 13
Start of period 13: minute
2
R/W
00B9H
Start of period 13: hour
Rate no. of period 14
2
R/W
00BAH
Start of period 14: minute
Start of period 14: hour
2
R/W
00BBH
Rate no. of period 9
Start of period 9: minute
2
R/W
The second time list
Rate No.:
1: sharp
2: peak
3: flat
4: Valley
0: no ratet
00BCH
Start of period 9: hour
Rate no. of period 10
2
R/W
00BDH
Start of period 10: minute
Start of period 10: hour
2
R/W
00BEH
Rate no. of period 11
Start of period 11: minute
2
R/W
00BFH
Start of period 11: hour
Rate no. of period 12
2
R/W
00C0H
Start of period 12: minute
Start of period 12: hour
2
R/W
00C1H
Rate no. of period 13
Start of period 13: minute
2
R/W
00C2H
Start of period 13: hour
Rate no. of period 14
2
R/W
00C3H
Start of period 14: minute
Start of period 14: hour
2
R/W
00C4H
…
0163H
Reserved
0164H
Active power of A phase
4
R
PQS=data*PT*CT*0.
001
Unit:KW(active)
kVar(reactive)
kVA(apparent)
Active power and
0166H
Active power of B phase
4
R
0168H
Active power of C phase
4
R
016AH
Total active power
4
R
016CH
Reactive power of A phase
4
R
