24
06A1H
Harmonic current on B phase
2
06A2H
Harmonic current on C phase
2
06A3H
Fundamental active power on A
phase
2
Int
Keep 3 decimal places
06A4H
Fundamental active power on B
phase
2
06A5H
Fundamental active power on C
phase
2
06A6H
Total fundamental active power
2
06A7H
Fundamental reactive power on A
phase
2
06A8H
Fundamental reactive power on B
phase
2
06A9H
Fundamental reactive power on C
phase
2
06AAH
Total fundamental reactive power
2
06ABH
Harmonic active power on A phase
2
06ACH
Harmonic active power on B phase
2
06ADH
Harmonic active power on C phase
2
06AEH
Total harmonic active power
2
06AFH
Harmonic reactive power on A
phase
2
06B0H
Harmonic reactive power on B
phase
2
06B1H
Harmonic reactive power on C
phase
2
06B2H
Total harmonic reactive power
2
9.4 SOE record
Address
Name
Data list
Name
3001H
Last event record
0000H
Occur date: YY-MM
3002H
Last 2 event record
0001H
Occur time: DD-hh
…
…
0002H
Occur time: mm-ss
3064H
Last 100 event record
0004H
Event number
0005H
Event details
0006H
Reserve
Event num
Name
Details
Note
0100/0101
Power on/off
0200
Clear
0001
Clear current energy
0002
Clear history energy on
Flash
