25
0003
Clear maximum demand
0004
Clear history energy
0005
Clear maximum value on a
period
0006
Clear out
0300
DO action
0000
DO off
0001
DO on
0400
UI record
UI
Bit0:
Over-voltage on A phase
Bit1:
Over-voltage on B phase
Bit2:；
Over-voltage on C phase
Bit3:
Lose-voltage on A phase
Bit4:
Lose-voltage on B phase
Bit5:
Lose-voltage on C phase
Bit6:
Reversing on A phase
Bit7:
Reversing on B phase
Bit8:
Reversing on C phase
Bit9:
Over current on A phase
Bit10:
Over current on B phase
Bit11:
Over current on C phase
Bit12:
Low current on A phase
Bit13:
Low current on B phase
Bit14:
Low current on C phase
0700
Time calibration
Example: The address is 001 at present, and we send the code: 01 03 30 01 00 06
9B 08 to get the last event record, and the slave station will give back: 01 03 0C 12 01
08 0A 01 01（2018/1/8 10:1:1）01 00（powered）00 00（no details）00 00（reserved）
80 23
