P a g e 12 SAF’IR EVOLUTION Instruction Manual
Inserting the mouthpiece
When the instrument is ready for the test, remove the mouthpiece from the bag and insert it
as shown below:
Insert a mouthpiece into the sampling port
on the upper left part of the instrument.
Slide the mouthpiece into place and turn it
slightly if necessary.
Push the mouthpiece in full lock.
Do a visual check if necessary: the mouthpiece
should be fitting the notch.
Each test requires the use of a new mouthpiece. If the
subject has to be retested, change the mouthpiece for
each test.
1 MOUTHPIECE = 1 TEST
