Acson AWM 25G Technical Manual

37
Engineering & Physical Data AWM-G-2009
General Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 20G AWM 20G
OUTDOOR UNIT ALC 18C ALC 20C
NOMINAL CAPACITY
Btu/h 18000 19000
W 5280 5570
NOMINAL TOTAL INPUT POWER W 1820 1807
NOMINAL RUNNING CURRENT A 8.10 8.00
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 2.90 3.08
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 231 / 490 231 / 490
MEDIUM l/s / CFM 193 / 410 193 / 410
LOW l/s / CFM 160 / 340 160 / 340
SOUND PRESSURE LEVEL (H/M/L) dBA 43 / 40 / 35 43 / 40 / 35
UNIT DIMENSION
HEIGHT mm/in 304 / 12.0 304 / 12.0
WIDTH mm/in 1062 / 41.8 1062 / 41.8
DEPTH mm/in 222 / 8.7 222 / 8.7
PACKING DIMENSION
HEIGHT mm/in 378 / 14.9 378 / 14.9
WIDTH mm/in 1130 / 44.5 1130 / 44.5
DEPTH mm/in 292 / 11.5 292 / 11.5
UNIT WEIGHT kg/lb 16 / 35.3 16 / 35.3
CONDENSATE DRAIN SIZE mm/in 20 / 0.8 20 / 0.8
OUTDOOR UNIT
AIR FLOW l/s / CFM 614 / 1300 614 / 1300
SOUND PRESSURE LEVEL dBA 51 51
UNIT DIMENSION
HEIGHT mm/in 654 / 25.7 654 / 25.7
WIDTH mm/in 855 / 33.7 855 / 33.7
DEPTH mm/in 328 / 12.9 328 / 12.9
PACKING DIMENSION
HEIGHT mm/in 710 / 28.0 710 / 28.0
WIDTH mm/in 990 / 39.0 990 / 39.0
DEPTH mm/in 415 / 16.3 415 / 16.3
UNIT WEIGHT kg/lb 58 / 127.9 59 / 130.1
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 15.88 / 5/8 15.88 / 5/8
REFRIGERANT CHARGE kg/lb 0.63 / 1.39 0.60 / 1.33
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
