Acson AWM 25G Technical Manual

38
AWM-G-2009 Engineering & Physical Data
General Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 25G AWM 301
OUTDOOR UNIT ALC 25C ALC 28C
NOMINAL CAPACITY
Btu/h 23500 27000
W 6890 7913
NOMINAL TOTAL INPUT POWER W 2530 2708
NOMINAL RUNNING CURRENT A 11.30 13.10
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 2.72 3.00
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
AUTO LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 297 / 630 316 / 670
MEDIUM l/s / CFM 231 / 490 297 / 630
LOW l/s / CFM 208 / 440 236 / 500
SOUND PRESSURE LEVEL (H/M/L) dBA 49 / 44 / 42 49 / 47 / 45
UNIT DIMENSION
HEIGHT mm/in 304 / 12.0 360 / 14.2
WIDTH mm/in 1062 / 41.8 1200 / 47.2
DEPTH mm/in 222 / 8.7 200 / 7.9
PACKING DIMENSION
HEIGHT mm/in 378 / 14.9 420 / 16.5
WIDTH mm/in 1130 / 44.5 1267 / 49.9
DEPTH mm/in 292 / 11.5 260 / 10.2
UNIT WEIGHT kg/lb 16 / 35.3 17 / 37.48
CONDENSATE DRAIN SIZE mm/in 20 / 0.8 20 / 0.8
OUTDOOR UNIT
AIR FLOW l/s / CFM 755 / 1600 741 / 1570
SOUND PRESSURE LEVEL dBA 52 54
UNIT DIMENSION
HEIGHT mm/in 756 / 29.8 756 / 29.8
WIDTH mm/in 855 / 33.7 855 / 33.7
DEPTH mm/in 328 / 12.9 328 / 12.9
PACKING DIMENSION
HEIGHT mm/in 810 / 31.9 810 / 31.9
WIDTH mm/in 990 / 39.0 990 / 39.0
DEPTH mm/in 415 / 16.3 415 / 16.3
UNIT WEIGHT kg/lb 62 / 136.7 65 / 143.3
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 9.52 / 3/8 9.52 / 3/8
GAS mm/in 15.88 / 5/8 15.88 / 5/8
REFRIGERANT CHARGE kg/lb 1.5 / 3.30 2.10 / 4.63
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.

Acson AWM 25G Specifications

General

Brand	Acson
Model	AWM 25G
Category	Air Conditioner
Language	English
