Acson AWM 25G Technical Manual

39
Engineering & Physical Data AWM-G-2009
General Data - Heat pump (R22)
MODEL
INDOOR UNIT AWM 09GR AWM 10GR
OUTDOOR UNIT ALC 09CR ALC 10CR
NOMINAL COOLING CAPACITY
Btu/h 8800 9500
W 2580 2780
NOMINAL HEATING CAPACITY
Btu/h 8600 9500
W 2520 2780
NOMINAL TOTAL INPUT POWER (COOLING) W 910 860
NOMINAL TOTAL INPUT POWER (HEATING) W 750 750
NOMINAL RUNNING CURRENT (COOLING) A 4.00 3.80
NOMINAL RUNNING CURRENT (HEATING) A 3.40 3.40
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 2.84 3.23
COP W/W 3.36 3.71
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 130 / 275 142 / 300
MEDIUM l/s / CFM 106 / 225 118 / 250
LOW l/s / CFM 83 / 175 94 / 200
SOUND PRESSURE LEVEL (H/M/L) dBA 40 / 35 / 29 39 / 34 / 28
UNIT DIMENSION
HEIGHT mm/in 260 / 10.2 260 / 10.2
WIDTH mm/in 799 / 31.5 899 / 35.4
DEPTH mm/in 198 / 7.8 198 / 7.8
PACKING DIMENSION
HEIGHT mm/in 337 / 13.3 337 / 13.3
WIDTH mm/in 857 / 33.7 957 / 37.7
DEPTH mm/in 270 / 10.6 270 / 10.6
UNIT WEIGHT kg/lb 10 / 22.5 12 / 26.5
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW l/s / CFM 307 / 650 396 / 840
SOUND PRESSURE LEVEL dBA 46 46
UNIT DIMENSION
HEIGHT mm/in 495 / 19.5 540 / 21.3
WIDTH mm/in 600 / 23.6 700 / 27.6
DEPTH mm/in 245 / 9.7 250 / 9.8
PACKING DIMENSION
HEIGHT mm/in 575 / 22.6 620 / 24.4
WIDTH mm/in 715 / 28.1 810 / 31.9
DEPTH mm/in 330 / 13.0 330 / 13.0
UNIT WEIGHT kg/lb 28 / 61.7 32 / 70.5
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 9.52 / 3/8 9.52 / 3/8
REFRIGERANT CHARGE kg/lb 0.75/1.65 0.88 / 1.94
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
