MODEL: ALC / A4LC 30C
100
1. BASE PAN 11. MOTOR BRACKET ASSY
2. FLARE VALVE 12. SIDE PANEL LEFT
3. FLARE VALVE 13. FAN MOTOR
4. PARTITION 14. FAN BLADE
5. COMPRESSOR 15. FRONT PANEL ASSY
6. ACCESS PANEL 16. TERMINAL BOX ASSY
7. ACCUMULATOR 17. PLATE, FLARE VALVE
8. BACK PANEL
9. TOP PANEL
10. COIL ASSY
