MODEL: A4LC 07BR / 10BR / 15BR
1. ASSY., BACK PANEL 13. NUT, COMPRESSOR
2. ASSY., TOP PANEL 14. ASSY., BASE PAN
3. ASSY, COIL OUTDOOR 15. ASSY., CAPILLARY TUBE
4. BRACKET, MOTOR MOUNTING 16. ASSY., PARTITION
5. FAN MOTOR 17. ASSY., TERMINAL BOX PANEL
6. FAN, 14" 18. ASSY., SIDE PANEL
7. ASSY., PANEL FRONT 19. ASSY., ACCESS PANEL
8. SCREW, FAN SET 20. PLATE, FLARE JOINT VALVE
9. ASSY., 4 WAY VALVE 21. VALVE, SUCTION
10. ROTARY COMPRESSOR 22. VALVE, LIQUID
11. RUBBER, GROMMET 23. CLIP, COIL SENSOR
12. WASHER, FLAT 24. SENSOR, OUTDOOR DEFROST
101
