MODEL: ALC 10CR / 15CR
1. ASSY. BASE PAN 9. MOTOR
2. ASSY. CONDENSER COIL 10. FAN, 16"
3. ASSY. VALVE BRACKET 11. ASSY. PANEL LEFT INS.
4. ASSY. COMPRESSOR 12. ASSY. PANEL RIGHT INS.
5. ASSY. 4 WAYS VALVE 13. ASSY. CONTROL PANEL
6. ASSY. CAP. TUBE 14. ASSY. FRONT PANEL INS.
7. ASSY. INS. PARTITION 15. ASSY. VALVE COVER
8. BRACKET, MOTOR
105
