Acson awm10f User Manual

MODEL: ALC 10C / 15C
1. ASSY. BASE PAN 9. ASSY. PANEL LEFT INS.
2. ASSY. CONDENSER COIL 10. ASSY. PANEL RIGHT INS.
3. ASSY. COMPRESSOR 11. BRACKET, MOTOR
4. ASSY. VALVE BRCKET 12. MOTOR
5. ASSY. PARTITION INS. 13. ASSY. CONTROL PANEL
6. ASSY. CAP. TUBE 14. ASSY. VALVE COVER
7. TUBE, DISCHARGE 15. ASSY. FRONT PANEL INS.
8. TUBE, SUCTION 16. FAN, 16"
104
