Acson awm10f User Manual

R22 MODELS
(COOLING ONLY)
MODEL : AWM 301 / ALC 30B
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 7.743 4.459 7.364 4.208 6.985 3.957 6.606 3.706 6.290 3.416 5.959 3.115 5.702 2.880 5.415 2.618
16 8.254 4.098 7.804 3.892 7.354 3.686 6.903 3.480 6.572 3.201 6.227 2.911 5.958 2.685 5.658 2.432
16 8.254 5.486 7.804 5.280 7.354 5.074 6.903 4.868 6.572 4.590 6.227 4.299 5.958 4.073 5.658 3.821
17 8.765 5.125 8.244 4.964 7.722 4.803 7.200 4.642 6.855 4.374 6.495 4.095 6.214 3.878 5.901 3.636
18 9.276 4.765 8.683 4.648 8.090 4.532 7.497 4.416 7.138 4.159 6.763 3.891 6.471 3.683 6.145 3.450
19 9.787 4.404 9.123 4.332 8.459 4.261 7.794 4.190 7.421 3.944 7.031 3.688 6.727 3.488 6.388 3.265
20 10.300 4.040 9.582 3.991 8.863 3.942 8.145 3.893 7.754 3.661 7.347 3.420 7.029 3.231 6.676 3.022
18 9.276 6.153 8.683 6.037 8.090 5.920 7.497 5.804 7.138 5.548 6.763 5.280 6.471 5.071 6.145 4.839
19 9.787 5.792 9.123 5.721 8.459 5.650 7.794 5.578 7.421 5.333 7.031 5.076 6.727 4.876 6.388 4.653
20 10.300 5.428 9.582 5.379 8.863 5.330 8.145 5.281 7.754 5.050 7.347 4.808 7.029 4.620 6.676 4.410
21 10.815 5.063 10.053 5.021 9.292 4.979 8.531 4.937 8.122 4.722 7.695 4.497 7.362 4.322 6.992 4.128
22 11.329 4.698 10.525 4.662 9.721 4.627 8.917 4.592 8.489 4.394 8.043 4.186 7.696 4.025 7.308 3.845
23 11.843 4.332 10.996 4.304 10.150 4.276 9.303 4.247 8.857 4.065 8.391 3.875 8.029 3.728 7.625 3.563
24 12.358 3.967 11.468 3.945 10.578 3.924 9.689 3.903 9.224 3.737 8.739 3.565 8.362 3.430 7.941 3.280
20 10.300 6.123 9.582 6.074 8.863 6.024 8.145 5.975 7.754 5.744 7.347 5.502 7.029 5.314 6.676 5.104
21 10.815 5.757 10.053 5.715 9.292 5.673 8.531 5.631 8.122 5.416 7.695 5.191 7.362 5.017 6.992 4.822
22 11.329 5.392 10.525 5.357 9.721 5.321 8.917 5.286 8.489 5.088 8.043 4.880 7.696 4.719 7.308 4.539
23 11.843 5.026 10.996 4.998 10.150 4.970 9.303 4.942 8.857 4.760 8.391 4.570 8.029 4.422 7.625 4.257
24 12.358 4.661 11.468 4.640 10.578 4.618 9.689 4.597 9.224 4.432 8.739 4.259 8.362 4.124 7.941 3.974
HIGH AMBIENT
30
ID WB°C
Outdoor DB°C
20 25 30
20
24
28
ID DB°C 40 4635 50 54
MODEL : AWM 301 / ALC 30C
17
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15
8.455 5.195 8.082 4.927 7.708 4.659 7.334 4.392 6.983 4.073 6.616 3.741 6.330 3.482 6.011 3.193
16
8.904 4.821 8.492 4.593 8.079 4.365 7.666 4.136 7.298 3.830 6.915 3.510 6.616 3.261 6.283 2.984
16
8.904 6.167 8.492 5.939 8.079 5.710 7.666 5.482 7.298 5.176 6.915 4.856 6.616 4.607 6.283 4.329
17 9.353 5.793 8.901 5.604 8.449 5.416 7.997 5.227 7.614 4.932 7.214 4.625 6.902 4.386 6.555 4.120
18 9.802 5.420 9.311 5.270 8.820 5.121 8.329 4.971 7.929 4.689 7.512 4.395 7.188 4.166 6.826 3.911
19 10.251 5.047 9.721 4.936 9.190 4.826 8.660 4.716 8.245 4.446 7.811 4.165 7.474 3.945 7.098 3.701
20 10.700 4.671 10.127 4.580 9.554 4.490 8.982 4.399 8.551 4.144 8.101 3.879 7.752 3.672 7.361 3.441
18 9.802 6.766 9.311 6.616 8.820 6.466 8.329 6.317 7.929 6.035 7.512 5.741 7.188 5.511 6.826 5.256
19 10.251 6.392 9.721 6.282 9.190 6.172 8.660 6.061 8.245 5.792 7.811 5.510 7.474 5.291 7.098 5.047
20 10.700 6.017 10.127 5.926 9.554 5.835 8.982 5.744 8.551 5.490 8.101 5.224 7.752 5.018 7.361 4.787
21 11.149 5.639 10.531 5.555 9.914 5.471 9.297 5.386 8.851 5.149 8.386 4.901 8.023 4.709 7.620 4.494
22
11.597 5.262 10.935 5.184 10.273 5.106 9.612 5.029 9.151 4.808 8.670 4.579 8.295 4.400 7.878 4.200
23
12.045 4.885 11.339 4.813 10.633 4.742 9.927 4.671 9.451 4.468 8.954 4.256 8.567 4.091 8.136 3.907
24
12.494 4.507 11.743 4.443 10.992 4.378 10.242 4.313 9.751 4.127 9.238 3.933 8.839 3.782 8.394 3.614
20 10.700 6.689 10.127 6.599 9.554 6.508 8.982 6.417 8.551 6.163 8.101 5.897 7.752 5.690 7.361 5.460
21 11.149 6.312 10.531 6.228 9.914 6.144 9.297 6.059 8.851 5.822 8.386 5.574 8.023 5.381 7.620 5.166
22 11.597 5.935 10.935 5.857 10.273 5.779 9.612 5.701 9.151 5.481 8.670 5.251 8.295 5.073 7.878 4.873
23 12.045 5.557 11.339 5.486 10.633 5.415 9.927 5.343 9.451 5.140 8.954 4.929 8.567 4.764 8.136 4.580
24 12.494 5.180 11.743 5.115 10.992 5.050 10.242 4.986 9.751 4.800 9.238 4.606 8.839 4.455 8.394 4.286
HIGH AMBIENT
30
50 54
20
28
30 35 40
24
ID DB°C ID WB°C
Outdoor DB°C
20 25 46
