R22 MODELS
(HEATPUMP)
MODEL : AWM 10FR / ALC 10CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.165 1.854 2.945 1.677 2.725 1.500 2.505 1.323 2.285 1.147 2.021 0.934
16 3.260 1.681 3.030 1.533 2.799 1.385 2.569 1.237 2.338 1.088 2.061 0.911
16
3.260 2.288 3.030 2.139 2.799 1.991 2.569 1.843 2.338 1.695 2.061 1.517
17
3.355 2.114 3.114 1.995 2.873 1.876 2.632 1.756 2.391 1.637 2.102 1.494
18 3.450 1.941 3.199 1.851 2.947 1.760 2.695 1.669 2.444 1.579 2.142 1.470
19 3.546 1.768 3.283 1.706 3.021 1.644 2.759 1.583 2.497 1.521 2.182 1.446
20
3.642 1.594 3.377 1.551 3.113 1.507 2.848 1.464 2.584 1.421 2.266 1.369
18
3.450 2.548 3.199 2.457 2.947 2.367 2.695 2.276 2.444 2.186 2.142 2.077
19 3.546 2.375 3.283 2.313 3.021 2.251 2.759 2.189 2.497 2.127 2.182 2.053
20 3.642 2.201 3.377 2.157 3.113 2.114 2.848 2.071 2.584 2.027 2.266 1.975
21
3.738 2.026 3.477 1.994 3.216 1.963 2.955 1.931 2.693 1.899 2.380 1.862
22
3.835 1.851 3.577 1.831 3.319 1.811 3.061 1.791 2.803 1.772 2.493 1.748
23 3.932 1.675 3.677 1.667 3.422 1.660 3.167 1.652 2.913 1.644 2.607 1.634
24 4.029 1.500 3.777 1.504 3.525 1.508 3.274 1.512 3.022 1.516 2.720 1.520
20
3.642 2.504 3.377 2.461 3.113 2.417 2.848 2.374 2.584 2.331 2.279 2.279
21
3.738 2.329 3.477 2.297 3.216 2.266 2.955 2.234 2.693 2.203 2.380 2.165
22 3.835 2.154 3.577 2.134 3.319 2.114 3.061 2.095 2.803 2.075 2.493 2.051
23
3.932 1.979 3.677 1.971 3.422 1.963 3.167 1.955 2.913 1.947 2.607 1.937
24
4.029 1.804 3.777 1.808 3.525 1.811 3.274 1.815 3.022 1.819 2.720 1.824
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
HEATING MODE
18
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 1.644 1.644 1.854 1.854 1.924 1.924 2.694 2.694 3.115 3.115 3.325 3.325 3.535 3.535
17 1.623 1.623 1.836 1.836 1.907 1.907 2.724 2.724 3.087 3.087 3.295 3.295 3.503 3.503
19
1.603 1.603 1.818 1.818 1.889 1.889 2.754 2.754 3.059 3.059 3.265 3.265 3.472 3.472
21
1.583 1.583 1.800 1.800 1.872 1.872 2.784 2.784 3.031 3.031 3.236 3.236 3.440 3.440
23
1.574 1.574 1.785 1.785 1.855 1.855 2.703 2.703 3.003 3.003 3.206 3.206 3.409 3.409
25 1.565 1.565 1.769 1.769 1.838 1.838 2.622 2.622 2.976 2.976 3.176 3.176 3.377 3.377
27 1.556 1.556 1.754 1.754 1.820 1.820 2.541 2.541 2.948 2.948 3.147 3.147 3.346 3.346
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
