Acson awm10f User Manual

R407C MODELS
(HEATPUMP)
MODEL : AWM 07FR / A4LC 07BR
COOLING MODE
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15
2.685 1.492 2.486 1.314 2.288 1.137 2.089 0.959 1.890 0.782 1.652 0.568
16 2.673 1.327 2.489 1.183 2.304 1.039 2.120 0.896 1.936 0.752 1.715 0.580
16
2.673 1.939 2.489 1.795 2.304 1.651 2.120 1.508 1.936 1.364 1.715 1.192
17 2.660 1.773 2.491 1.664 2.321 1.554 2.152 1.444 1.983 1.334 1.779 1.203
18 2.647 1.608 2.493 1.532 2.338 1.456 2.183 1.381 2.029 1.305 1.843 1.214
19 2.635 1.442 2.495 1.401 2.355 1.359 2.215 1.317 2.075 1.275 1.907 1.225
20 2.622 1.275 2.496 1.254 2.369 1.233 2.243 1.212 2.116 1.191 1.964 1.165
18
2.647 2.220 2.493 2.144 2.338 2.068 2.183 1.993 2.029 1.917 1.843 1.826
19 2.635 2.055 2.495 2.013 2.355 1.971 2.215 1.929 2.075 1.887 1.907 1.837
20
2.622 1.888 2.496 1.866 2.369 1.845 2.243 1.824 2.116 1.803 1.964 1.778
21 2.609 1.720 2.495 1.710 2.382 1.701 2.268 1.691 2.154 1.682 2.017 1.671
22 2.596 1.551 2.495 1.554 2.394 1.556 2.293 1.559 2.192 1.561 2.070 1.564
23 2.584 1.383 2.495 1.398 2.406 1.412 2.318 1.426 2.229 1.441 2.123 1.458
24 2.571 1.215 2.495 1.242 2.419 1.268 2.343 1.294 2.267 1.320 2.176 1.351
20
2.622 2.194 2.496 2.172 2.369 2.151 2.243 2.130 2.116 2.109 2.084 2.084
21 2.609 2.026 2.495 2.016 2.382 2.007 2.268 1.998 2.154 1.988 2.017 1.977
22
2.596 1.858 2.495 1.860 2.394 1.862 2.293 1.865 2.192 1.867 2.070 1.870
23 2.584 1.689 2.495 1.704 2.406 1.718 2.318 1.732 2.229 1.747 2.123 1.764
24 2.571 1.521 2.495 1.548 2.419 1.574 2.343 1.600 2.267 1.626 2.176 1.657
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
HEATING MODE
27
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 1.222 1.222 1.391 1.391 1.447 1.447 2.066 2.066 2.403 2.403 2.572 2.572 2.740 2.740
17 1.204 1.204 1.377 1.377 1.434 1.434 2.100 2.100 2.382 2.382 2.549 2.549 2.716 2.716
19
1.186 1.186 1.363 1.363 1.421 1.421 2.134 2.134 2.360 2.360 2.526 2.526 2.691 2.691
21
1.168 1.168 1.348 1.348 1.408 1.408 2.169 2.169 2.339 2.339 2.503 2.503 2.667 2.667
23
1.165 1.165 1.338 1.338 1.395 1.395 2.095 2.095 2.317 2.317 2.480 2.480 2.643 2.643
25 1.161 1.161 1.327 1.327 1.382 1.382 2.021 2.021 2.296 2.296 2.457 2.457 2.618 2.618
27 1.158 1.158 1.317 1.317 1.369 1.369 1.947 1.947 2.274 2.274 2.434 2.434 2.594 2.594
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
