R407C MODELS
(HEATPUMP)
MODEL : AWM 10FR / A4LC 10BR
COOLING MODE
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 2.848 1.622 2.669 1.476 2.490 1.330 2.311 1.184 2.132 1.038 1.918 0.863
16 2.968 1.494 2.774 1.363 2.580 1.232 2.386 1.101 2.191 0.970 1.958 0.812
16 2.968 2.064 2.774 1.933 2.580 1.802 2.386 1.670 2.191 1.539 1.958 1.382
17
3.088 1.936 2.879 1.820 2.669 1.703 2.460 1.587 2.250 1.471 1.999 1.331
18 3.208 1.809 2.983 1.707 2.759 1.605 2.534 1.504 2.309 1.402 2.039 1.280
19 3.328 1.681 3.088 1.594 2.848 1.507 2.608 1.420 2.368 1.333 2.080 1.229
20 3.449 1.553 3.201 1.477 2.953 1.401 2.705 1.325 2.457 1.249 2.159 1.157
18 3.208 2.378 2.983 2.277 2.759 2.175 2.534 2.073 2.309 1.971 2.039 1.849
19
3.328 2.251 3.088 2.164 2.848 2.077 2.608 1.990 2.368 1.903 2.080 1.799
20 3.449 2.122 3.201 2.046 2.953 1.970 2.705 1.894 2.457 1.818 2.159 1.727
21 3.570 1.994 3.319 1.926 3.068 1.858 2.816 1.790 2.565 1.722 2.264 1.641
22 3.692 1.866 3.437 1.806 3.183 1.746 2.928 1.686 2.673 1.626 2.368 1.555
23 3.813 1.737 3.555 1.686 3.297 1.634 3.040 1.582 2.782 1.531 2.473 1.469
24
3.934 1.609 3.673 1.565 3.412 1.522 3.151 1.478 2.890 1.435 2.577 1.383
20 3.449 2.407 3.201 2.331 2.953 2.255 2.705 2.179 2.457 2.103 2.159 2.011
21 3.570 2.279 3.319 2.211 3.068 2.143 2.816 2.075 2.565 2.007 2.264 1.925
22
3.692 2.150 3.437 2.091 3.183 2.031 2.928 1.971 2.673 1.911 2.368 1.839
23 3.813 2.022 3.555 1.970 3.297 1.919 3.040 1.867 2.782 1.815 2.473 1.753
24
3.934 1.894 3.673 1.850 3.412 1.807 3.151 1.763 2.890 1.720 2.577 1.667
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
HEATING MODE
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 1.501 1.501 1.675 1.675 1.733 1.733 2.373 2.373 2.721 2.721 2.895 2.895 3.070 3.070
17 1.487 1.487 1.660 1.660 1.718 1.718 2.510 2.510 2.697 2.697 2.870 2.870 3.042 3.042
19
1.472 1.472 1.645 1.645 1.702 1.702 2.647 2.647 2.673 2.673 2.844 2.844 3.015 3.015
21
1.458 1.458 1.629 1.629 1.687 1.687 2.784 2.784 2.648 2.648 2.818 2.818 2.988 2.988
23
1.445 1.445 1.615 1.615 1.671 1.671 2.596 2.596 2.624 2.624 2.792 2.792 2.960 2.960
25 1.433 1.433 1.600 1.600 1.656 1.656 2.408 2.408 2.600 2.600 2.766 2.766 2.933 2.933
27 1.420 1.420 1.585 1.585 1.640 1.640 2.220 2.220 2.575 2.575 2.741 2.741 2.906 2.906
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
