ACT Technology ACTSmart 2 1070 - Quick IO Setup; Adding a Card Batch for Second Door; Adding a PIN for Second Door; Adding a Card and PIN for Second Door

Step Keypad Entry Operation
170 Add Card Batch for Second Door
(I/O function code 12 must be set for the Aux O/P)
2 Present Card First card in Batch (lowest number card)
3 Present Card Last Card in Batch (highest number card)
4 Enter 1-8, (optional)* Select each door this batch enabled for
5 Press
✔
End programming card batch.
Note: the buzzer will sound while cards are loaded into memory.
ACTSmart2 Operating and Installation Manual Rev. 1.0
13
Quick IO Setup:
Step Keypad Entry Operation
153 Set Input Output Functions (0 - is default)
2 0-9 Select a code
Prog Input AUX IO 1 AUX IO 2
0 Door Release Button Door Contact Door Alarm
1 Door Release Button Door Contact Buzzer
2 Door Release Button Door Contact Interlock
3 Door Release Button Door Contact SmartLock
4 Door Release Button Fire Override Interlock
5 Door Contact Follow Door Alarm
6 Door Contact Follow Buzzer
7 Door Contact Door Alarm Buzzer
8 Fire Override Interlock Buzzer
9 Card And PIN Interlock Follow
3 1-8 (optional)* Select each door this function is valid for
4 Press
✔
End Quick IO setup
Adding a PIN for Second Door:
Step Keypad Entry Operation
171 Add PINs (Make sure Option 40 is set on PIN and Prox units.)
(I/O function code 12 must be set for the Aux O/P)
2 0001-9999 4 - 6 digit PIN code
3 1-8, (optional)* Select each door this PIN is valid for
4 Press
✔
End programming PINs
Adding a Card and PIN for Second Door:
Adding a Card Batch for Second Door:
Step Keypad Entry Operation
172 Add Card and PIN (Make sure Option 39 is set on PIN and Prox units.)
(I/O function code 12 must be set for the Aux O/P)
2 Present Card
3 0001-9999 4 - 6 digit PIN code
4 1-8, (optional)* Select each door this Card & PIN is valid for
5 Press
✔
End programming Card and PINs
