ACTsmart2 Operating and Installation Manual Rev. 1.3
16
Setting Programmable Input Function:
Step Keypad Entry Operation
1 50 Set Input Function (Door Release button is default)
2 00-06 Select 2-digit I/O Function Code (see below for explanation of codes)
3 1-8 (optional)* Select each door this function is valid for
4 Press
End programming Input Function
Setting AUX I/O 1 Function:
Step Keypad Entry Operation
1 51 Set AUX I/O 1 Function (Door Contact is default)
2 00-19 Select 2-digit I/O Function Code (see below)
3 1-8 (optional)* Select each door this function is valid for
4 Press
End programming AUX I/O 1
Setting AUX I/O 2 Function:
Step Keypad Entry Operation
1 52 Set AUX I/O 2 Function (Door Alarm is default)
2 00-19 Select 2-digit I/O Function Code (see below)
3 1-8 (optional)* Select each door this function is valid for
4 Press
End programming AUX I/O 2
I/O Function Codes:
Code Function Operation
00 Door Contact Input required if you wish to monitor Door Forced or Door Ajar
01 Fire Alarm Override When this input is high, the door is opened and the green LED flashes (See
Fire Alarm Override Connections diagram). If this is wired into the Master
Smart, then all doors on the network will open.
02 Lock Door When this input is low, the door locks and the red LED flashes.
03 Card and PIN When this input is low, then only users who enter both Card and PIN will be
admitted. This option is only valid on anACTsmart2 PIN and PROX unit (1080).
04 Card or PIN When this input is low, a valid Card or a valid PIN will open the door. This
option is only valid on an ACTsmart2 PIN and PROX unit (1080).
05 Door Release Button When this input is low, the door opens.
06 Second Door Release When this input is low, any I/Os configured as Second Door Lock will open
Button for the Door Relay Time.
07 Interlock This normally behaves as an input and locks the door while the input is low.
While the door relay is active or the Door Contact is open, it becomes an
active output. (See Interlock Connections diagram).
08 Door Alarm This output activates while an alarm is present - A door alarm may be a door
forced, door ajar, tamper or duress.
09 Follow This output follows the state of the door relay.
10 Buzzer This output activates for Door Chime or Door Alarms.
11 SmartLock This output controls a Smart Lock device for Secure doors.
12 Second Door Lock This output will activate for the Door Relay Time when a valid card or PIN is
presented. See commands 70-73.
continued
ACTsmart2 Mar/Apr 08:ACTsmart2 Mar 08 29/04/2008 17:03 Page 16
