ACT ACTsmart2 Series Operating And Installation Instructions

ACTsmart2 Operating and Installation Manual Rev. 1.3
17
Quick IO Setup:
Step Keypad Entry Operation
1 53 Set Input Output Functions (0 - is default)
2 0-9 Select a code
Prog Input AUX IO 1 AUX IO 2
0 Door Release Button Door Contact Door Alarm
1 Door Release Button Door Contact Buzzer
2 Door Release Button Door Contact Interlock
3 Door Release Button Door Contact SmartLock
4 Door Release Button Fire Override Interlock
5 Door Contact Follow Door Alarm
6
1
Data Clock Door Armed
7 Door Contact Door Alarm Buzzer
8 Fire Override Interlock Buzzer
9 Card And PIN Interlock Follow
3 1-8 (optional)* Select each door this function is valid for
4 Press
✔
End Quick IO setup
I/O Function Codes (continued)
Code Function Operation
14 Door Armed This output toggles when a user with the armed function presses the
✔
key and
then presents a valid card or PIN. This can be used to arm or disarm an alarm panel.
The output may be set to pulse for 2 seconds instead of toggle. See Option 43.
15 Panel Armed Input When this input is low, the door is locked and the red LED flashes. This input
informs the ACTsmart2 that the panel is armed. (See the Alarm Panel Wiring
diagram).
18 Green LED This output follows the state of the green LED.
19 Red LED This ouput follows the state of the red LED.
1
The Quick IO setup allows the ACTsmart2 unit to be connected to the ACTpro-X family of Clock and Data readers
(code number 6). This feature allows an ACTpro-X reader to be installed on the non-secure side of the door and the
ACTsmart2 to be inside the secure area. This prevents tampering with the lock relay from the outside. See the
ACTpro-X Connections diagram.
ACTsmart2 Mar/Apr 08:ACTsmart2 Mar 08 29/04/2008 17:03 Page 17
