Technical Specifications
Name of product REVITIVE Medic
Model 2469MD
Weight 1.5kg
Dimensions
Ø360mm x 75mm (isorocker enabled)
Ø360mm x 100.5mm (isorocker disabled)
Power Consumption 5W
Power Source:
AC adapter – UL (Underwriters
Laboratories) Safety Mark
Input
Output
100-240V, 50/60Hz, 0.18A.
5.0Vdc, 1.0A
Battery Lithium Ion, 1200mAh, 3.7V
Battery Life 500 charge cycles
Output Specifications:
Waveform Monophasic
Shape Square symmetrical with polarity reversal
Maximum Output Voltage: @500Ω Foot: 35V Body: 19V
@2kΩ
Foot: 101V Body: 54V
@10kΩ
Foot: 133V Body: 68V
Maximum Output Current: @ 500Ω Foot: 71mA Body: 39mA
@2kΩ
Foot: 51mA Body: 27mA
@10kΩ
Foot: 13mA Body: 7mA
Pulse Duration:
Foot: 450 +/- 45µs
or 970 +/- 97µs
Body: 450 +/- 45µs
The Remote Control replicates the controls found on the device
Operating Frequencies 38 KH
z
Operating Range Distance
0 to 25m at horizontal
0 to 18m at +/- 30 degree angle
from the horizontal.
Frequency:
Foot: 20 to 43Hz, Body: 38 to 51Hz
Net Charge @ 500Ω [0.004]mC
Maximum Phase Charge @ 500 Ω Foot: 53µC Body: 17µC
Maximum Current Density Foot: 0.032 mA/cm² Body: 0.100 mA/cm²
Maximum Power Density @ 500Ω
Foot: 0.81 mW/cm² Body: 1.82 mW/cm²
Burst Mode: a. Pulses per burst Foot: 195 - 1092 Body: 291 - 921
b. Bursts per second
Foot: 0.11 - 0.29 Body: 0.10 - 0.30
c. Burst duration
Foot: 1.91 - 8.35s Body: 1.90 - 6.50s
d. Duty Cycle Foot: 0.56 - 0.89 Body: 0.65 - 0.86
ON Time Foot: 1.90 - 8.40s Body: 1.90 - 6.50s
OFF Time
Foot: 1.00 - 1.50s Body: 1.00s
Disposal: At the end of product life do not throw this product into normal household garbage, but
take it to a collection point for the recycling of electronic equipment.
