Acteon X-MIND trium - Page 9

Pag 9 of 11
Quality assessment checks
Perform the next operations with XMIND Trium ON completely covered with the plastics
PAN Quality Check
" Absence of artifacts
□
P
□
F
Verify that the exposed area is smooth and
without artifacts
see Quality
assessment
manual
PAN Quality Check
" High Contrast
Resolution
□
P
□
F
Verify that the High Contrast resolution is
at least 3.1 Lp/mm
see Quality
assessment
manual
PAN Quality Check
" Low Contrast
Resolution
□
P
□
F
Verify the Low Contrast resolution,
checking that all the four holes are visible.
see Quality
assessment
manual
CEPH Quality Check
" Absence of artifacts
□
P
□
F
Verify that the exposed area is smooth and
without artifacts
see Quality
assessment
manual
CEPH Quality Check
" High Contrast
Resolution
□
P
□
F
Verify that the High Contrast resolution is
at least 3.1 Lp/mm
see Quality
assessment
manual
CEPH Quality Check
" Low Contrast
Resolution
□
P
□
F
Verify the Low Contrast resolution,
checking that all the four holes are visible.
see Quality
assessment
manual
CBCT 80x80 Quality
Check
" Homogeneity
□
P
□
F
Verify that the Homogeneity of the 80x80
FOV Test is in the acceptance range 15.0 ±
5
Measured value (SW output)_______________
see Quality
assessment
manual
CBCT 80x80 Quality
Check
" CNR
□
P
□
F
Verify that the CNR of the 80x80 FOV Test
is > 5.0
Measured value (SW output)_______________
see Quality
assessment
manual
CBCT 80x80 Quality
Check
" V
10%
□
P
□
F
Verify that the V
10%
of the 80x80 FOV Test
is > 1.6 LP/mm
Measured value (SW output)_______________
see Quality
assessment
manual
CBCT 80x80 Quality
Check
" V
50%
□
P
□
F
Verify that the V
50%
of the 80x80 FOV Test
is > 0.5 LP/mm
Measured value (SW output)_______________
see Quality
assessment
manual
CBCT 110x80 Quality
Check
" Homogeneity
□
P
□
F
Verify that the Homogeneity of the 110x80
FOV Test is in the acceptance range 12.0 ±
5
Measured value (SW output)_______________
see Quality
assessment
manual
CBCT 110x80 Quality
Check
" CNR
□
P
□
F
Verify that the CNR of the 110x80 FOV Test
is > 4.0
Measured value (SW output)_______________
see Quality
assessment
manual
CBCT 110x80 Quality
Check
" V
10%
□
P
□
F
Verify that the V
10%
of the 110x80 FOV Test
is in the acceptance range
is > 1.5 LP/mm
Measured value (SW output)_______________
see Quality
assessment
manual
