Physical Description
NOTE: The camera images on this documentation are for reference only. Actual camera may
slightly differ.
Item
Description
1
Ethernet Port
Connects to a network using an Ethernet cable.
2
Memory Card
Slot
Insert a memory card into this slot for local recording
purposes. See How to Install a Memory Card on page
28 for more information.
NOTE: Supports microSDHC and microSDXC cards.
3
Reset Button
Restores the factory default settings of the camera. To
reset the camera, while the power is on, press and hold
the Reset Button for at least 5 seconds or until the red
LED beneath the camera module lights up.
4
DC 12V Power
Input
In case the camera is connected to a non-PoE (Power
over Ethernet) switch, use this connector to connect the
camera to an external power adapter. See Connecting
a Power Adapter (Optional) on page 14 for more
information.
