ActronAir LM Series Service Manual

7
ActronAir
®
is constantly seeking ways to improve the design of it’s products, therefore specifi cations are subject to change without notice. Please check prior to purchase.
Copyright © 2014 Actron Engineering Pty. Ltd.
LM SERIES CONTROL / INSTALLATION DIAGRAM
LM-SERIES CONTROLLER WITH OPTIONAL 8 ZONE 24VAC ZONE MODULE (8Z-24V)
3
IMPORTANT NOTE: Use the supplied screws to mount the Zone Module onto the Fan Coil unit using the
pre-drilled holes near the control panel on the Fan Coil side.
CONDENSER CPU BOARD
TO VSD
Data Cable - Cut-off screen wire & clamp
screen foil with metal P-clip unto OD control
panel. Ensure good earth connection with
screen foil
ON
11
2345678
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
NOTES:
1. DIAGRAM SHOWN ABOVE IS A GENERAL PRESENTATION ONLY. REFER TO INDIVIDUAL UNIT WIRING
DIAGRAM FOR COMPLETE WIRING CONNECTION DETAILS AND SPECIFICATIONS.
2. APPLICABLE TO ESP PLATINUM PLUS MODELS ONLY.
OPTIONAL
8-ZONE 24VAC INTEGRATED ZONE BARRELS
(ZB-10-250 / ZB-12-300 / ZB-14-350 / ZB-16-400)
OPTIONAL
8-ZONE 24VAC ZONE MODULE
(8Z-24V)
OPTIONAL
WALL CONTROLLER 2
(MIMIC LOGIC)
WALL CONTROLLER 1
INDOOR UNIT
INDOOR BOARD
2 CORE & EARTH CABLE
(230VAC) - 2m long
2 CORE 14/0.20 (0.44mm)
Shielded Data Cable -2m long
OPTIONAL
ACTRONAIR ZONE BARREL CABLES
CAT5E Cable with Basic Non-Moulded RJ45 Plug
8 - ZONE MODULE COMPATIBILITY
INDOOR BOARD 8Z-24V
AMIB-P1VV * Yes
* Available to R410A ESP Platinum Plus
models only,
SENSOR
KEY
COMMON
POWER
SENSOR
KEY
COMMON
POWER
AERSS
OPTIONAL
DUCT BEAD SENSOR
(Supplied with Cable)
LM-RS
OPTIONAL
REMOTE SENSOR
2 CORE 14/0.20 (0.44mm)
Shielded Data Cable
OUTDOOR UNIT
Field Wiring by Installer
2 CORE & EARTH CABLE (230VAC)
Field Wiring by Installer
Cable must be 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair
Shielded Cable with Screen Foil clamped to a Metal P-Clip
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
AMIB-P1VV
2020-132
E
A B
DATA /
COM / B
S - 2
S - 1/G
KEY/Y
P W R
COM / B
SCRN
A N E
240V Mains
Cable to AMIB
Indoor Unit
Blue
Brown
Green /Yellow
24 VAC
Outputs
ZONE
8
ZONE
4
ZONE
7
ZONE
3
ZONE
6
ZONE
2
ZONE
5
ZONE
1
A
N
E
Data
Cable
to
AMIB
Indoor
Unit
DATA
COM
White
Black
SCRN Blue
M-SERIES
8 ZONE MODULE
Part No. 8Z-24V
WARNING
DAMAGEDUE TO
INCORRECTWIRING
VOIDSWARRANTY
ON / OFF ZONING
INTERNAL
2A FUSE
