ActronAir LM7-D Service Manual

5
ActronAir
®
is constantly seeking ways to improve the design of it’s products, therefore specifi cations are subject to change without notice. Please check prior to purchase.
Copyright © 2014 Actron Engineering Pty. Ltd.
LM SERIES CONTROL / INSTALLATION DIAGRAM
LM-SERIES CONTROLLER WITH OPTIONAL 4 ZONE 24 VOLT KIT (4Z-24V)
1
R
®
NOTE:
DIAGRAM SHOWN ABOVE IS A GENERAL PRESENTATION ONLY. REFER TO INDIVIDUAL UNIT WIRING DIAGRAM
FOR COMPLETE WIRING CONNECTION DETAILS AND SPECIFICATIONS.
OPTIONAL
WALL CONTROLLER 2
(MIMIC LOGIC)
WALL CONTROLLER 1
2 CORE 14/0.20 (0.44mm
2
)
Shielded Data Cable
AERSS
OPTIONAL
DUCT BEAD SENSOR
LM-RS
OPTIONAL
REMOTE SENSOR
INDOOR UNIT
Field Wiring by Installer
2 CORE & EARTH CABLE (230VAC)
OPTIONAL
4-ZONE 24VAC INTEGRATED ZONE BARRELS
(ZB-10-250 / ZB-12-300 / ZB-14-350 / ZB-16-400)
OPTIONAL
ACTRONAIR ZONE BARREL CABLES
CAT5E Cable with Basic Non-Moulded RJ45 Plug
NEUT
ACT
CLOSE OPEN CLOSE OPEN CLOSE OPEN
COM
24VAC
MAINS
240V
RLY
24V ZONE CARD
TRANSFORMER
ZONE 1 ZONE 2 ZONE 3 ZONE 4
AMZ-24V
RLY 1RLY 2
23002-2
RLY 3
AMZL2
RLY 4
Z1
P1
P2
Z2 Z3 Z4
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
E
DATA /
COM / B
S - 2
S - 1/G
KEY/Y
P W R
AMIB-3
COM / B
COIL OUT
A B C D E
COIL IN
EXV
G A B
SCRN
HIGH
MID
LOW
NEUT
A N E
ActronAir
INDOOR FAN 230V
2020-XXX
AMIB-PXXX
PCB S/N
P.3.X.1.0.0
CONDENSER CPU BOARD
NEUT NEUT NEUT NEUT
LOW
HIGH
ACT
ETH
COMP
LP
LP
HP
REV
HP
N2132
COMP
COM
FAN
HEAT
NEUT
NEUT
ACT
HIGH
LOW
15V
DATA
SCRN
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
4 CORE 14/0.20 (0.44mm)
Shielded Data Cable
SENSOR
KEY
COMMON
POWER
SENSOR
KEY
COMMON
POWER
4Z-24V ZONE KIT COMPATIBILITY
INDOOR BOARD 4Z-24V
AMIB-P * Yes
* Available to all R410A split residential
models, except ESP Ultima &
ESP Platinum Ultima
OPTIONAL
4 - ZONE 24VAC ZONE CARD
AND TRANSFORMER
(4Z-24V KIT)
Field Wiring by Installer
Cable must be 2 CORE 14/0.20 (0.44mm
2
) Screened Cable
or 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair Shielded Cable
OUTDOOR UNIT
Cable must be 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair Shielded Data Cable
®
