LM7 / LM7-D / LM24 / LM24W Service Manual
Version 4.0 140402
LM SERIES CONTROL / INSTALLATION DIAGRAM
LM-SERIES CONTROLLER WITH OPTIONAL 8 ZONE 24VAC ZONE MODULE (8Z-24V)
2
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
E
DATA /
COM / B
S - 2
S - 1/G
KEY/Y
P W R
AMIB-3
COM / B
COIL OUT
A B C D E
COIL IN
EXV
G A B
SCRN
HIGH
MID
LOW
NEUT
A N E
ActronAir
INDOOR FAN 230V
2020-XXX
AMIB-PXXX
PCB S/N
P.3.X.1.0.0
OPTIONAL
DUCT BEAD SENSOR
(Supplied with Cable)
R
®
NOTES:
1. DIAGRAM SHOWN ABOVE IS A GENERAL PRESENTATION ONLY. REFER TO INDIVIDUAL UNIT WIRING
DIAGRAM FOR COMPLETE WIRING CONNECTION DETAILS AND SPECIFICATIONS.
2. NOT APPLICABLE TO ESP ULTIMA, ESP PLATINUM ULTIMA & ESP PLATINUM PLUS MODELS.
OPTIONAL
8-ZONE 24VAC INTEGRATED ZONE BARRELS
(ZB-10-250 / ZB-12-300 / ZB-14-350 / ZB-16-400)
OPTIONAL
8-ZONE 24VAC ZONE MODULE
(8Z-24V)
OPTIONAL
WALL CONTROLLER 2
(MIMIC LOGIC)
WALL CONTROLLER 1
CONDENSER CPU BOARD
4 CORE 14/0.20 (0.44mm)
Shielded Data Cable
INDOOR UNIT
INDOOR
BOARD
2 CORE 14/0.20 (0.44mm)
Shielded Data Cable
2 CORE & EARTH CABLE
(230VAC) - 2m long
2 CORE Twisted Data Cable
with Shield
OPTIONAL
ACTRONAIR ZONE BARREL CABLES
CAT5E Cable with Basic Non-Moulded RJ45 Plug
NEUT NEUT NEUT NEUT
LOW
HIGH
ACT
ETH
COMP
LP
LP
HP
REV
HP
N2132
COMP
COM
FAN
HEAT
NEUT
NEUT
ACT
FAN
ON/OFF
15V
DATA
SCRN
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
8 - ZONE MODULE COMPATIBILITY
INDOOR BOARD 8Z-24V
AMIB-P * Yes
* Available to all R410A split residential
models, except ESP Ultima,
ESP Platinum Ultima & ESP Platinum Plus
SENSOR
KEY
COMMON
POWER
SENSOR
KEY
COMMON
POWER
LM-RS
OPTIONAL
REMOTE SENSOR
Field Wiring by Installer
2 CORE & EARTH CABLE (230VAC)
OUTDOOR UNIT
Field Wiring by Installer
Cable must be 2 CORE 14/0.20 (0.44mm
2
) Screened Cable
or 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair Shielded Cable
240V Mains
Cable toAMIB
Indoor Unit
Blue
Brown
Green /Yellow
24 VAC
Outputs
ZONE
8
ZONE
4
ZONE
7
ZONE
3
ZONE
6
ZONE
2
ZONE
5
ZONE
1
A
N
E
Data
Cable
to
AMIB
Indoor
Unit
DATA
COM
White
Black
SCRN Blue
M-SERIES
8 ZONE MODULE
Part No. 8Z-24V
WARNING
DAMAGEDUE TO
INCORRECTWIRING
VOIDSWARRANTY
ON / OFF ZONING
INTERNAL
2A FUSE
®
IMPORTANT NOTE: Use the supplied screws to mount the Zone Module onto the Fan Coil unit using the
pre-drilled holes near the control panel on the Fan Coil side.
Cable must be 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair
Shielded Data Cable
®
